| Standard Capacities (Kg.) |
| 3, 6, 10, 20, 40, 45, 80 |
|
| |
 |
| |
 |
|
|
| Standard Specification : |
| Nominal Output |
2.0 ± 0.1 mV/V (mili Volt per Volt) |
| Precision |
C2 / C3 (0.017% & 0.02% FSO comprehensive error) |
| Excitation Voltage |
9 VDC - Maximum 12 VDC |
| Platter Size |
250mm x 350mm |
| Safe Load |
120% of Rated Capacity |
| Ultimate Load |
150% of Rated Capacity |
| Non Linearity |
<±0.03% of FSO (Full Scale Output) |
| Creep (30 minutes) |
<±0.025% of FSO |
| Zero Balance |
<±1% of FSO |
| Input Resistance |
400 ± 10 ohms |
| Output Resistance |
350 ± 5 ohms |
| Insulation resistance |
Above 5000 Mega ohms |
| Temp. Compensation |
-10oC to +40oC |
| Temp. Effect on zero & span |
< 0.03% FSO/10oC |
| Material |
Alluminium alloy, Colourless anodized |
| Cable |
4mm, 0.42 mts |
|
| |
| |
|
